Pixel Pitch: P1.25mm, P1.5mm, P1.9mm, P2.5mm, P2.6mm, P2.9mm, P3.9mm, P4.8mm

S40 SERIES

Lightest 500mm LED Panel in the World.

THINNEST CABINET RENTAL & FIX

4.8 kg / panel 100% front maintenance

MULTIPLE APPLICATIONS

MODULAR DESIGN

CORNER CUBE CURVE

MULTIPLE DIRECTIONS

SHOP GLASS APPLICATION

AR STUDIO

THICKNESS

IMMERSIVE SHOP

THICKNESS

SHELF MODULE

BOOTH INSTALLATION STEPS

APPLICATIONS

SPECIFICATIONS

 Model No. S 1.25 S 1.5 S 1.9 S 2.5 S 2.6 S 2.9 S 3.9 S 4.8
Application Indoor (IP30) Indoor (IP30) Indoor (IP30) Indoor (IP30) Indoor (IP30) Indoor (IP30) Indoor (IP30) Indoor (IP30)
Pixel Pitch (mm) 1.25 1.5625 1.953 2.5 2.604 2.976 3.906 4.808
LED Encapsulation SMD 1010 SMD 1212 SMD 1515 SMD 2020 SMD 1515 SMD 2121 SMD 2121 SMD 2121
Scan Mode 1/40 scan 1/40 scan 1/32 scan 1/34 scan 1/24 scan 1/28 scan 1/16 scan 1/13 scan
Brightness (nits) 600 nits 600 nits 700 nits 750 nits 800 nits 800 nits 800 nits 800 nits
Pixel Density (dot/m2) 640,000 4,096,00 262,144 160,000 147,456 112,896 65,536 43,264
Module Size (mm) 250mm x 250mm 250mm x 250mm 250mm x 250mm 250mm x 250mm 250mm x 250mm 250mm x 250mm 250mm x 250mm 250mm x 250mm
Module Resolution 200 x 200 160 x 160 128 x 128 100 x 100 96 x 96 84 x 84 64 x 64 52 x 52
Cabinet Size (mm) 500 x 500 x 40mm 500 x 500 x 40mm 500 x 500 x 40mm 500 x 500 x 40mm 500 x 500 x 40mm 500 x 500 x 40mm 500 x 500 x 40mm 500 x 500 x 40mm
Cabinet Resolution 400 x 400 320 x 320 256 x 256 200 x 200 192 x 192 168 x 168 128 x 128 104 x 104
Max. Power Consumpution (W/m2) 600 600 600 500 500 500 500 500
Ave. Power Consumpution (W/m2) 225 225 225 200 200 200 200 200
Cabinet weight (kg) 4.8 kg / panel 4.8 kg / panel 4.8 kg / panel 4.8 kg / panel 4.8 kg / panel 4.8 kg / panel 4.8 kg / panel 4.8 kg / panel
Refresh Rates (Hz) 3840 Hz 3840 Hz 3840 Hz 3840 Hz 3840 Hz 3840 Hz 3840 Hz 3840 Hz
Grey Level 16bit 16bit 16bit 16bit 16bit 16bit 16bit 16bit
LED Control System Novastar Novastar Novastar Novastar Novastar Novastar Novastar Novastar
