Pixel Pitch: P1.25mm, P1.56mm, P1.953mm, P2.0mm, P2.5mm, P3.076mm, P4mm
FLEXIBLE
Flexible MIP – 3500 ~4000 nits
Flexible 250 – 700 nits
Flexible 320 – 700 nits
Flexible Outdoor
4 TYPES FLEXIBLE
FLEXIBLE MIP
FLEXIBLE MIP
SPECIFICATIONS
| Model | MIP1.25 | MIP1.5625 |
|---|---|---|
| Pixel Configuration | 1R1G1B (Full Color) | 1R1G1B (Full Color) |
| LED Package Specification | 0606 | 0606 |
| Pixel Density (dots/m²) | 640,000 | 409,600 |
| Module Dimensions (mm) | 300 x 168.75 x 4.1 (Length x Height x Thickness) | 300 x 168.75 x 4.1 (Length x Height x Thickness) |
| Module Resolution | 240 x 135 | 192 x 108 |
| Scan Mode | 1/60 Scan | 1/50 Scan |
| Technical Parameters | ||
| Standard Constant Current IC | PWM | PWM |
| Refresh Frequency (Hz) | 3840 Hz | 3840 Hz |
| Frame Frequency (Hz) | 60 Hz | 60 Hz |
| Grayscale Level (bit) | 14 bit | 14 bit |
| Signal Interface Type | Custom (No Cascade Interface) | Custom (No Cascade Interface) |
| Module Backplate Material | Soft Silicone Backplate | Soft Silicone Backplate |
| Module Weight (g/unit) | 210g | 200g |
| Flatness (mm) | ≤0.3 mm | ≤0.3 mm |
| Module Protection Rating | Front IP65 | Front IP65 |
| Installation/Maintenance Method | Front or Rear Installation/Maintenance | Front or Rear Installation/Maintenance |
| Optical Parameters | ||
| Brightness (nits) | 3500 - 4000 nits | 3500 - 4000 nits |
| Color Temperature (K) | 6500-9300K Adjustable | 6500-9300K Adjustable |
| Chromaticity Coordinates | X:0.2800 Y:0.3000 | X:0.2800 Y:0.3000 |
| Horizontal/Vertical Viewing Angle | X:170° / Y:170° | X:170° / Y:170° |
| Contrast Ratio | 15000:1 | 15000:1 |
| Electrical Parameters | ||
| Module Supply Voltage DC (V) | R:2.8-3V / GB:3.8-4V | R:2.8-3V / GB:3.8-4V |
| Module Max Current DC (A) | R:1A / GB: 1.6A | R:1A / GB: 1.6A |
| Module Max Power Consumption (W/unit) | 10W | 10W |
| Operating Input Voltage AC (V) | 220 V | 220 V |
| Peak Power Consumption (W/m²) | 220W | 220W |
| Average Power Consumption (W/m²) | 80W | 80W |
| Operating Parameters | ||
| Typical Lifespan (h) | 100,000h | 100,000h |
| Operating Temperature/Humidity Range | -10—40℃, 20%—90%RH (Non-condensing) | -10—40℃, 20%—90%RH (Non-condensing) |
| Storage Temperature/Humidity Range | -40—60°C, 20%—80%RH (Non-condensing) | -40—60°C, 20%—80%RH (Non-condensing) |
FLEXIBLE 250
FLEXIBLE 250
SPECIFICATIONS
| Model | P1.5625 | P1.953 | P2.604 |
|---|---|---|---|
| Pixel Configuration | 1R1G1B (Full Color) | 1R1G1B (Full Color) | 1R1G1B (Full Color) |
| LED Package Specification | SMD1212 | SMD1515 | SMD1515 |
| Pixel Density (dots/m²) | 409,600 | 262,144 | 147,456 |
| Module Dimensions (mm) | 250 x 250 x 4.5 (L x H x T) | 250 x 250 x 4.5 (L x H x T) | 250 x 250 x 4.5 (L x H x T) |
| Module Resolution | 160 x 160 | 128 x 128 | 96 x 96 |
| Scan Mode | 1/40 Scan | 1/32 Scan | 1/32 Scan |
| Refresh Frequency (Hz) | 3840 Hz | 3840 Hz | 3840 Hz - 7680 Hz |
| Frame Frequency (Hz) | 60 Hz | 60 Hz | 60 Hz |
| Grayscale Level (bit) | 14 bit | 14 bit | 14 bit |
| Assembly Diameter | Φ1114mm | 955mm | 637mm |
| Arc Curvature | ≥167° | ≥165° | ≥158° |
| Signal Interface Type | HUB75 (No Cascade Interface) | HUB75 (No Cascade Interface) | HUB75 (No Cascade Interface) |
| Module Backplate Material | Soft Silicone Backplate | Soft Silicone Backplate | Soft Silicone Backplate |
| Module Weight (g/unit) | 345g | 355g | 288g |
| Flatness between Modules (mm) | ≤0.3 mm | ≤0.3 mm | ≤0.3 mm |
| Installation/Maintenance Method | Front or Rear Installation/Maintenance | Front or Rear Installation/Maintenance | Front or Rear Installation/Maintenance |
| Brightness (cd) | 600 cd | 700 cd | 600-650 cd |
| Color Temperature (K) | 6500K-12000K Adjustable | 6500K-12000K Adjustable | 6500K-12000K Adjustable |
| Chromaticity Coordinates | X:0.2500 Y:0.3000 ± 0.01 | X:0.2500 Y:0.3000 ± 0.01 | X:0.2500 Y:0.3000 ± 0.01 |
| Horizontal/Vertical Viewing Angle | X:150° / Y:120° | X:150° / Y:120° | X:150° / Y:120° |
| Contrast Ratio | 6000:01:00 | 6000:01:00 | 6000:01:00 |
| Module Supply Voltage DC (V) | 5V | 5V | 5V |
| Module Max Current DC (A) | 7A | 6A | 6A |
| Module Max Power Consumption (W/unit) | 35W | 30W | 30W |
| Operating Input Voltage AC (V) | 220 V | 220 V | 220 V |
| Peak Power Consumption (W/m²) | 585W | 500W | 500W |
| Average Power Consumption (W/m²) | 205W | 175W | 175W |
| Typical Lifespan (h) | 100,000 h | 100,000 h | 100,000 h |
| Operating Temperature/Humidity | -10—40℃, 20%—85%RH (Non-condensing) | -10—40℃, 20%—85%RH (Non-condensing) | -10—40℃, 20%—85%RH (Non-condensing) |
| Storage Temperature/Humidity | -40—60℃, 20%—80%RH (Non-condensing) | -40—60℃, 20%—80%RH (Non-condensing) | -40—60℃, 20%—80%RH (Non-condensing) |
| Function | FLASH Storage Function (Optional) | FLASH Storage Function (Optional) | FLASH Storage Function (Optional) |
FLEXIBLE 320
FLEXIBLE 320
SPECIFICATIONS
| Model | P1.25 | P1.56 | P1.86 | P2.0 | P2.5 | P3.076 | P4 |
|---|---|---|---|---|---|---|---|
| Usage | Indoor | Indoor | Indoor | Indoor | Indoor | Indoor | Indoor |
| LEDs | SMD 1010 | SMD 1212 | SMD 1515 | SMD 1515 | SMD 1515 | SMD 2121 | SMD 2121 |
| Pixel Pitch (mm) | 1.25 | 1.568 | 1.86 | 2 | 2.5 | 3.076 | 4 |
| Brightness (nits) | 600 | 600 | 600 | 650 | 650 | 650 | 800 |
| Module Size (mm) | 320 x 160 | 320 x 160 | 320 x 160 | 320 x 160 | 320 x 160 | 320 x 160 | 320 x 160 |
| Resolution (dots) | 256 x 128 | 204 x 102 | 172 x 86 | 160 x 80 | 128 x 64 | 80 x 40 | 80 x 40 |
| Module Weight (kg) | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 | 0.3 |
| Interface | HUB75 | HUB75 | HUB75 | HUB75 | HUB75 | HUB75 | HUB75 |
| Design | 5V | 5V | 5V | 5V | 5V | 5V | 5V |
| Scan Mode | 1/48 | 1/51 | 1/43 | 1/40 | 1/32 | 1/26 | 1/20 |
| Color Temperature (K) | 6000-8000 | 6000-8000 | 6000-8000 | 6000-8000 | 6000-8000 | 6000-8000 | 6000-8000 |
| Refresh Rate (Hz) | ≥ 3840 | ≥ 3840 | ≥ 3840 | ≥ 3840 | ≥ 3840 | ≥ 3840 | ≥ 3840 |
| Maintenance Method | Front Service | Front Service | Front Service | Front Service | Front Service | Front Service | Front Service |
| Gray Scale | 8192 | 8192 | 8192 | 8192 | 8192 | 8192 | 8192 |
| Processing Depth (bit) | 13 | 13 | 13 | 13 | 13 | 13 | 13 |
| PCB Board Layers | 4 Layers | 4 Layers | 2 Layers | 2 Layers | 2 Layers | 2 Layers | 2 Layers |
| Module Power Consumption (W/pcs) | 25 | 22 | 20 | 20 | 19 | 19 | 22 |
| Degree of Protection | Front IP30 | Front IP30 | Front IP30 | Front IP30 | Front IP30 | Front IP30 | Front IP30 |
| Working Temperature (℃) | -20~+50 | -20~+50 | -20~+50 | -20~+50 | -20~+50 | -20~+50 | -20~+50 |
| Working Humidity (%RH) | 0~70 | 0~70 | 0~70 | 0~70 | 0~70 | 0~70 | 0~70 |
| Storage Temperature (℃) | -30~+60 | -30~+60 | -30~+60 | -30~+60 | -30~+60 | -30~+60 | -30~+60 |
| Storage Humidity (%RH) | 0~80 | 0~80 | 0~80 | 0~80 | 0~80 | 0~80 | 0~80 |
| Viewing Angle (°) | H160 / V140 | H160 / V140 | H160 / V140 | H160 / V140 | H160 / V140 | H160 / V140 | H160 / V140 |
| Life Time (Hours) | ≥100,000 | ≥100,000 | ≥100,000 | ≥100,000 | ≥100,000 | ≥100,000 | ≥100,000 |
FLEXIBLE OUTDOOR
FLEXIBLE OUTDOOR
SPECIFICATIONS
| Model | P4 |
|---|---|
| Pixel Configuration | 1R1G1B (Full Color) |
| LED Package Specification | SMD1921 |
| Pixel Density (dots/m²) | 62,500 |
| Module Dimensions (mm) | 480 x 160 x 10.8 (L x H x T) |
| Module Resolution | 120 x 40 |
| Scan Mode | 1/10 Scan |
| Standard Constant Current IC | PWM |
| Refresh Frequency (Hz) | ≥3840 |
| Frame Frequency (Hz) | 60 |
| Grayscale Level (bit) | 15 |
| Minimum Assembly Diameter | 917mm |
| Minimum Arc Curvature | ≥150° |
| Signal Interface Type | HUB75 |
| Module Backplate Material | PC+GF |
| Module Weight (g/unit) | 560 |
| Flatness (mm) | ≤0.4 |
| Module Protection Rating | IP65 |
| Installation/Maintenance Method | Front Installation / Front & Rear Maintenance |
| Brightness (cd) | 4500 |
| Color Temperature (K) | 9000-9500 K Adjustable |
| Chromaticity Coordinates | X:0.2800 Y:0.3000 ± 0.01 |
| Horizontal/Vertical Viewing Angle | X:140° / Y:120° |
| Contrast Ratio | 3000:01:00 |
| Module Supply Voltage DC (V) | 4.2-5V |
| Module Max Current DC (A) | 10 |
| Module Max Power Consumption (W/unit) | 50 |
| Operating Input Voltage AC (V) | 100-240 |
| Peak Power Consumption (W/m²) | 670 |
| Average Power Consumption (W/m²) | 190 |
| Typical Lifespan (h) | 100,000 |
| Operating Temperature Range (°C) | -20 — 50 °C |
| Operating Humidity Range (RH) | 20% — 90%RH |
